Musikanlæg Bang & Olufsen nyt stue set up 5000
3.579 visninger
|
Oprettet:
Musikanlæg Bang & Olufsen nyt stue set up
Prisklasse:
5000
Forstærker/reciever:
Beomater 5500
Types:
2331 (1986 - March 1990)
AUS 2335 (1986 - Aug 1989)
GB 2332 (1986 - March 1990)
J 2334 (1986 - Oct 1989)
US 2333 (1986 - Dec 1989)
Long-term max. output power IEC 2 z 110 / 8 ohms
Power output 20 - 20,000 Hz IHF 2 x 50 W / 8 ohms
Total harmonic distortion IHF < 0.09 % / 8 ohms 20 - 20,000 Hz
Intermodulation IHF < 0.1 %
Signal-to-noise ratio:
TAPE A-weighted: >78 d
PHONO A-weighted: >80 dB
Channel separation: 10000 Hz 60 dB
FM range 87.5 - 108 MHz
LW range 150 - 350 kHz
MW range 520 - 1610 kHz
Power supply:
2331: 220 V
2332/2335: 240 V
2334: 100 V
Power consumption. max 225 W
Dimensions W x H x D: 42 x 7.5 x 32.5cm
Weight: 8.5 kg
RIAA amplifier: built-in
Connections: Beocord Tape 1 7 pole DIN, Datalink
Beocord Tape 2 7 pole DIN, Datalink
Beogram CD 7 pole DIN, Datalink
Beogram LP 7 pole DIN, Datalink
Beovox/BeoLab 4 pole DIN
Beovision 7 pole DIN, Datalink
Link room: Speaker set Master Control Link
Line IN/OUT Phono plugs
Extra speakers Phono plugs
Link compatibility: Master Control Link
Types:
2331 (1986 - March 1990)
AUS 2335 (1986 - Aug 1989)
GB 2332 (1986 - March 1990)
J 2334 (1986 - Oct 1989)
US 2333 (1986 - Dec 1989)
Long-term max. output power IEC 2 z 110 / 8 ohms
Power output 20 - 20,000 Hz IHF 2 x 50 W / 8 ohms
Total harmonic distortion IHF < 0.09 % / 8 ohms 20 - 20,000 Hz
Intermodulation IHF < 0.1 %
Signal-to-noise ratio:
TAPE A-weighted: >78 d
PHONO A-weighted: >80 dB
Channel separation: 10000 Hz 60 dB
FM range 87.5 - 108 MHz
LW range 150 - 350 kHz
MW range 520 - 1610 kHz
Power supply:
2331: 220 V
2332/2335: 240 V
2334: 100 V
Power consumption. max 225 W
Dimensions W x H x D: 42 x 7.5 x 32.5cm
Weight: 8.5 kg
RIAA amplifier: built-in
Connections: Beocord Tape 1 7 pole DIN, Datalink
Beocord Tape 2 7 pole DIN, Datalink
Beogram CD 7 pole DIN, Datalink
Beogram LP 7 pole DIN, Datalink
Beovox/BeoLab 4 pole DIN
Beovision 7 pole DIN, Datalink
Link room: Speaker set Master Control Link
Line IN/OUT Phono plugs
Extra speakers Phono plugs
Link compatibility: Master Control Link
Tuner
Indbygget i Beomaster 5500
Cd-afspiller
Beogram cd500 som desværre er defekt
Types:
2331 (1986 - March 1990)
AUS 2335 (1986 - Aug 1989)
GB 2332 (1986 - March 1990)
J 2334 (1986 - Oct 1989)
US 2333 (1986 - Dec 1989)
Long-term max. output power IEC 2 z 110 / 8 ohms
Power output 20 - 20,000 Hz IHF 2 x 50 W / 8 ohms
Total harmonic distortion IHF < 0.09 % / 8 ohms 20 - 20,000 Hz
Intermodulation IHF < 0.1 %
Signal-to-noise ratio:
TAPE A-weighted: >78 d
PHONO A-weighted: >80 dB
Channel separation: 10000 Hz 60 dB
FM range 87.5 - 108 MHz
LW range 150 - 350 kHz
MW range 520 - 1610 kHz
Power supply:
2331: 220 V
2332/2335: 240 V
2334: 100 V
Power consumption. max 225 W
Dimensions W x H x D: 42 x 7.5 x 32.5cm
Weight: 8.5 kg
RIAA amplifier: built-in
Connections: Beocord Tape 1 7 pole DIN, Datalink
Beocord Tape 2 7 pole DIN, Datalink
Beogram CD 7 pole DIN, Datalink
Beogram LP 7 pole DIN, Datalink
Beovox/BeoLab 4 pole DIN
Beovision 7 pole DIN, Datalink
Link room: Speaker set Master Control Link
Line IN/OUT Phono plugs
Extra speakers Phono plugs
Link compatibility: Master Control Link
Types:
2331 (1986 - March 1990)
AUS 2335 (1986 - Aug 1989)
GB 2332 (1986 - March 1990)
J 2334 (1986 - Oct 1989)
US 2333 (1986 - Dec 1989)
Long-term max. output power IEC 2 z 110 / 8 ohms
Power output 20 - 20,000 Hz IHF 2 x 50 W / 8 ohms
Total harmonic distortion IHF < 0.09 % / 8 ohms 20 - 20,000 Hz
Intermodulation IHF < 0.1 %
Signal-to-noise ratio:
TAPE A-weighted: >78 d
PHONO A-weighted: >80 dB
Channel separation: 10000 Hz 60 dB
FM range 87.5 - 108 MHz
LW range 150 - 350 kHz
MW range 520 - 1610 kHz
Power supply:
2331: 220 V
2332/2335: 240 V
2334: 100 V
Power consumption. max 225 W
Dimensions W x H x D: 42 x 7.5 x 32.5cm
Weight: 8.5 kg
RIAA amplifier: built-in
Connections: Beocord Tape 1 7 pole DIN, Datalink
Beocord Tape 2 7 pole DIN, Datalink
Beogram CD 7 pole DIN, Datalink
Beogram LP 7 pole DIN, Datalink
Beovox/BeoLab 4 pole DIN
Beovision 7 pole DIN, Datalink
Link room: Speaker set Master Control Link
Line IN/OUT Phono plugs
Extra speakers Phono plugs
Link compatibility: Master Control Link
Pladespiller
ingen endnu :)
Båndoptager
BeoCord 5500 Cassette Deck
Type:
4931 (1986 - Sept 1990)
AUS 4935 (1986 - Aug 1989)
GB 4932 (1986 - Jan 1990)
J 4934 (1986 - Jan 1990)
USA 4933 (1986 - Jan 1990)
Compact cassette: C46-C60-C90-C120
Recording system: HX PRO
Tape transport system: Auto reverse
Search system: Track numbers
Record level: Auto Recording level
Noise reduction: Auto Dolby B and C
Tape switch: Auto. ferro/chrom/metal
Tape head: Sendust
Wow and flutter DIN: <+/- 0.15%
Fast forward and rewind: C60 75 sec
Frequency range chrome: 30 - 18,000 Hz +/- 3 dB
Signal-to-noise ratio metal Dolby NR: B: >66 dB, C: >73 dB
Signal-to-noise ratio chrome Dolby NR B: >64 dB, C: >74 dB
Signal-to-noise ratio ferro Dolby NR B: >62 dB, C: >72 dB
Power supply 4931 220V
4932 240V
4933 120V
4934 100V
4935 240V
Power consumption: max. 25 W
Dimensions W x H x D 42 x 7.5 x 32.5cm
Weight 8 kg
Connections: AUX IN 7 pin
Microphone DIN 0,3mV /3kohms
Audio Link
Type:
4931 (1986 - Sept 1990)
AUS 4935 (1986 - Aug 1989)
GB 4932 (1986 - Jan 1990)
J 4934 (1986 - Jan 1990)
USA 4933 (1986 - Jan 1990)
Compact cassette: C46-C60-C90-C120
Recording system: HX PRO
Tape transport system: Auto reverse
Search system: Track numbers
Record level: Auto Recording level
Noise reduction: Auto Dolby B and C
Tape switch: Auto. ferro/chrom/metal
Tape head: Sendust
Wow and flutter DIN: <+/- 0.15%
Fast forward and rewind: C60 75 sec
Frequency range chrome: 30 - 18,000 Hz +/- 3 dB
Signal-to-noise ratio metal Dolby NR: B: >66 dB, C: >73 dB
Signal-to-noise ratio chrome Dolby NR B: >64 dB, C: >74 dB
Signal-to-noise ratio ferro Dolby NR B: >62 dB, C: >72 dB
Power supply 4931 220V
4932 240V
4933 120V
4934 100V
4935 240V
Power consumption: max. 25 W
Dimensions W x H x D 42 x 7.5 x 32.5cm
Weight 8 kg
Connections: AUX IN 7 pin
Microphone DIN 0,3mV /3kohms
Audio Link
DVD/Video
Lige pt en billig no-name dvd afspiller
BeoCord V8000 VHS VCR Product Specifications
Dimensions W x H x D / Weight:
38 x 10 x 28 cm / 4.3 kg
Cabinet finish:
White, black, silver, red, green, blue
Remote control: Beo4, Beo1
Tuner range: VHF, S, Hyper, UHF
CTV system: According to type: B/G/L/L/I/D/K PAL, SECAM*
TV programmes: 99
Stereo decoder: According to type: NICAM + A2, NICAM
Improved picture quality: Automatic optimised for own and rental tapes
Recording system:
HQ
PAL
Type 4605: PAL, SECAM, ME
SECAM to PAL transcoded recordings Slow motion: 1/2,1/12 x normal speed
Still picture: Noiseless
Tape counter: Time left, time used
Track marker: Set and erase
Timer programming: 8, 1 year
Sound system: Hi-Fi stereo
Video playing time, E-240: SP 4 hours, LP 8 hours (NTSC: SP, EP, LP)
Audio playing time, E-240: LP 8 hours
Connections:
AV: AV Link 21-pin socket
Camcorder IN: 3 phono sockets
V-Tape decoder: AV 21-pin socket
RF input socket: 75 ohms
RF output socket: 75 ohms
Cassette system: VHS
Quickloading: Yes
Subtitles from Teletext: Yes, in colours
On screen display: Yes
Playback of tapes recorded in:
NTSC 3.58 and NTSC 4.43 in Hi-Fi stereo sound
S-VHS (VHS quality)
Disc sizes: 12 cm - 8 cm
Frequency range: 20Hz - 20KHz
Playback the and rewind: Approx. 95 sec. E-180
Search forward/backward: PAL, SECAM: 5 x and 11 x normal speed,
Signal-to-noise-ratio SP mode:
Luminance >= 48 dB
Chrominance >= 38 dB (AM)
Chrominance >= 31 dB (PM)
Sound, compatible Hi-Fi/normal:
Stereo Hi-Fi/mono fixed head
Tape heads: 2 LP video, 2 SP video, 2 Hi-Fi sound
Sound frequency range: 20 - 20,000 Hz, 1 3 dB
Hi-Fi distortion: <= 1%
Signal-to-Noise ratio A-weighted: > 63 dB
Modulator tuning range: 471 - 855 MHz, System I
Power supply: 180 - 240 volts/50 Hz
Power consumption: Typical 22 watts / standby< 2.1 watts
*Type No. 4609: I, PAL, NICAM I
*Type No. 4601: B/G, PAL, NICAM B/G
Most recent S/W 3.13
BeoCord V8000 VHS VCR Product Specifications
Dimensions W x H x D / Weight:
38 x 10 x 28 cm / 4.3 kg
Cabinet finish:
White, black, silver, red, green, blue
Remote control: Beo4, Beo1
Tuner range: VHF, S, Hyper, UHF
CTV system: According to type: B/G/L/L/I/D/K PAL, SECAM*
TV programmes: 99
Stereo decoder: According to type: NICAM + A2, NICAM
Improved picture quality: Automatic optimised for own and rental tapes
Recording system:
HQ
PAL
Type 4605: PAL, SECAM, ME
SECAM to PAL transcoded recordings Slow motion: 1/2,1/12 x normal speed
Still picture: Noiseless
Tape counter: Time left, time used
Track marker: Set and erase
Timer programming: 8, 1 year
Sound system: Hi-Fi stereo
Video playing time, E-240: SP 4 hours, LP 8 hours (NTSC: SP, EP, LP)
Audio playing time, E-240: LP 8 hours
Connections:
AV: AV Link 21-pin socket
Camcorder IN: 3 phono sockets
V-Tape decoder: AV 21-pin socket
RF input socket: 75 ohms
RF output socket: 75 ohms
Cassette system: VHS
Quickloading: Yes
Subtitles from Teletext: Yes, in colours
On screen display: Yes
Playback of tapes recorded in:
NTSC 3.58 and NTSC 4.43 in Hi-Fi stereo sound
S-VHS (VHS quality)
Disc sizes: 12 cm - 8 cm
Frequency range: 20Hz - 20KHz
Playback the and rewind: Approx. 95 sec. E-180
Search forward/backward: PAL, SECAM: 5 x and 11 x normal speed,
Signal-to-noise-ratio SP mode:
Luminance >= 48 dB
Chrominance >= 38 dB (AM)
Chrominance >= 31 dB (PM)
Sound, compatible Hi-Fi/normal:
Stereo Hi-Fi/mono fixed head
Tape heads: 2 LP video, 2 SP video, 2 Hi-Fi sound
Sound frequency range: 20 - 20,000 Hz, 1 3 dB
Hi-Fi distortion: <= 1%
Signal-to-Noise ratio A-weighted: > 63 dB
Modulator tuning range: 471 - 855 MHz, System I
Power supply: 180 - 240 volts/50 Hz
Power consumption: Typical 22 watts / standby< 2.1 watts
*Type No. 4609: I, PAL, NICAM I
*Type No. 4601: B/G, PAL, NICAM B/G
Most recent S/W 3.13
Højttalere
Beovox RL 140 Passive Loudspeakers 4 styk
Type: Intro. year: Last sold:
6501 1986 05-92
6021 1986 02-94
Dimensions W x H x D 50 x 70 x 24 cm
Weight - 15 kg
Long-term max. input power - 200 watts
Maximum noise power - 140 watts
Speaker impedance - 8 ohms
Frequency range 40 - 20,000 Hz
Power at 96 dB SPL 2 watts
Sensitivity 1 W 93 dB
Distortion - < 0.5 %
Cabinet principle - Bass Reflex
Woofer 2 x 16.5 cm - 6½"
Tweeter 13 cm - 1"
Crossover frequency - 800/3000 Hz
Net volume - 38 litres
Connections - Spring Terminals
Type: Intro. year: Last sold:
6501 1986 05-92
6021 1986 02-94
Dimensions W x H x D 50 x 70 x 24 cm
Weight - 15 kg
Long-term max. input power - 200 watts
Maximum noise power - 140 watts
Speaker impedance - 8 ohms
Frequency range 40 - 20,000 Hz
Power at 96 dB SPL 2 watts
Sensitivity 1 W 93 dB
Distortion - < 0.5 %
Cabinet principle - Bass Reflex
Woofer 2 x 16.5 cm - 6½"
Tweeter 13 cm - 1"
Crossover frequency - 800/3000 Hz
Net volume - 38 litres
Connections - Spring Terminals
TV/Projektor
Beovision mx 7000
Specifications:
Dimensions W x H x D
65 x 67.5 x 46.5 cm
Weight
40.3 kg
Terminal included
Beo4
Picture tube
70 cm Black Line-s, Black Matrix
Visible picture
66 cm
Contrast screen
Grey glass
VisionClear
Auto picture adjustment
Auto cut-off
Wideband CTI
Dynamic luminance peaking
TV tuner range
45 - 865 MHz, VHF, S, Hyper, UHF
CTV system
According to type: B/G/D/K/L/L´/I/M PAL SECAM NTSC on AV
Teletext system
Improved Teletext, FastText, 6 languages, 4 memory page pr programme
TV programmes
59
Sound
Stereo, Active speakers
Sound pressure level
96 dB stereo
Stereo decoder/Bilingual
A2 + NICAM
Speaker system
Bass-reflex, two way
Power consumption/Minimum
Typical 95W / 2,4 W
Connections:
AV Link
2 x 21-pin sockets
Super VHS
YC playback 4-pin socket
Audio AUX Link
7-pin socket
Power Link
2 x 8-pin sockets
Stereo headphones
Jack socket 3.5 mm
Motorized stand operation
4-pin socket
Link compatibility:
Data Link
Specifications:
Dimensions W x H x D
65 x 67.5 x 46.5 cm
Weight
40.3 kg
Terminal included
Beo4
Picture tube
70 cm Black Line-s, Black Matrix
Visible picture
66 cm
Contrast screen
Grey glass
VisionClear
Auto picture adjustment
Auto cut-off
Wideband CTI
Dynamic luminance peaking
TV tuner range
45 - 865 MHz, VHF, S, Hyper, UHF
CTV system
According to type: B/G/D/K/L/L´/I/M PAL SECAM NTSC on AV
Teletext system
Improved Teletext, FastText, 6 languages, 4 memory page pr programme
TV programmes
59
Sound
Stereo, Active speakers
Sound pressure level
96 dB stereo
Stereo decoder/Bilingual
A2 + NICAM
Speaker system
Bass-reflex, two way
Power consumption/Minimum
Typical 95W / 2,4 W
Connections:
AV Link
2 x 21-pin sockets
Super VHS
YC playback 4-pin socket
Audio AUX Link
7-pin socket
Power Link
2 x 8-pin sockets
Stereo headphones
Jack socket 3.5 mm
Motorized stand operation
4-pin socket
Link compatibility:
Data Link
Ekstra udstyr
Master Control Panel 5500
Beo 4 fjernbetjening
Beo 4 fjernbetjening
Bemærkninger
Beovox rl140 er alle 4 renorveret med nye bass ophæng, anlæget spiller og lyder virkelig godt, alderen taget i betragtning
Musikanlæg Bang & Olufsen nyt stue set up
aug 2005
Følger: 55 Følgere: 65 AV-enheder: 8 Emner: 196 Svar: 4.569
Beklager det sene svar.
Nej jeg har ikke selv skiftet dem, det har min B&O mekaniker gjort for mig.
feb 2011
Følger: 2 Følgere: 1 Emner: 1 Svar: 2
Det er nu lidt sjovt, der er altid brok over at der ikke er tekst nok.......... Men her er der masser af det, og nu er det også galt..........?
Man skal vel ikke læse det hele hvis dette bliver for meget for de små øjne........ :o)
Kan ikke se problemet...........
