Bilstereo ALPINE R (SOLGT) [Tidl. AV-enhed]

2.074 visninger | Oprettet:
Bedømmelse

Du kan først stemme, når din egen av-enhed er oprettet og stemt ind. Opret din egen av-enhed

Stemmefordeling (4)
k.n .
k.n .
Mand | 32 år | Oprettet: 14. jun 2007
AV-enheder (2)
Forumemner (4)


Følger (9) Følgere (8)

Bilstereo ALPINE R (SOLGT)

Udfordringer
0
0
0
Udfordr
Prisklasse:
Forstærker/reciever:
MRV-F353 (CH1 – CH4) .............................. 30W, 0.08% THD

MRV-F303 (CH1 – CH4) .............................. 30W, 0.08% THD

MRV-T503 ................................................. 50W, 0.08% THD

MRV-T303 (CH1 – CH4) .............................. 30W, 0.08% THD

Per channel into 2 ohms

MRV-F353 (CH1 – CH4) ................................. 40W, 0.3% THD

MRV-F303 (CH1 – CH4) ................................. 40W, 0.3% THD

MRV-T503 ............................................... 100W, 0.3% THD

MRV-T303 ................................................. 50W, 0.3% THD

Bridged into 4 ohms

MRV-F353 (CH1 – CH4) ................................. 80W, 0.3% THD

MRV-F303 (CH1 – CH4) ................................. 80W, 0.3% THD

MRV-T503 ............................................... 200W, 0.3% THD

MRV-T303 ............................................... 100W, 0.3% THD

Power Output: RMS Continuous Power (at 12.0V, 20 Hz)

4 ohms

MRV-F353 (CH5) ..................................... 100W, 0.3% THD

Power Output: RMS Continuous Power (at 14.4V, 20 Hz to 20

kHz)

Per channel into 4 ohms

MRV-F353 (CH1 – CH4) ................................ 50W, 0.08% THD

MRV-F303 (CH1 – CH4) ................................ 50W, 0.08% THD

MRV-T503 .............................................. 75W, 0.08% THD

MRV-T303 .............................................. 50W, 0.08% THD

Per channel into 2 ohms

MRV-F353 (CH1 – CH4) .................................. 60W, 0.3% THD

MRV-F303 (CH1 – CH4) .................................. 60W, 0.3% THD

MRV-T503 ............................................... 150W, 0.3% THD

MRV-T303 ................................................. 75W, 0.3% THD

Bridged into 4 ohms

MRV-F353 (CH1 – CH4) ............................... 120W, 0.3% THD

MRV-F303 (CH1 – CH4) ............................... 120W, 0.3% THD

MRV-T503 ............................................... 300W, 0.3% THD

MRV-T303 ............................................... 150W, 0.3% THD

Power Output: RMS Continuous Power (at 14.4V, 20 Hz)

4 ohms

MRV-F353 (CH5) ..................................... 150W, 0.3% THD

Max. Power (at 14.4V, 1 kHz)

Per channel into 4 ohms

MRV-F353 (CH1 – CH4) ................................. 90W, 10% THD

MRV-F303 (CH1 – CH4) ................................. 90W, 10% THD

MRV-T503 ................................................ 200W, 10% THD

MRV-T303 ................................................ 120W, 10% THD

Bridged into 4 ohms

MRV-F353 (CH1 – CH4) ............................... 240W, 0.3% THD

MRV-F303 (CH1 – CH4) ............................... 240W, 0.3% THD

MRV-T503 ............................................... 500W, 0.3% THD

MRV-T303 ............................................... 300W, 0.3% THD

Max. Power (at 14.4V, 20 Hz)

4 ohms

MRV-F353 (CH5) .......................................... 300W, 10% THD

Frequency Response ................... 10 Hz to 50 kHz (+0, –1 dB)

Signal-to-Noise Ratio (referenced to rated power) ..................

100 dBA

Slew factor ........................................................ Greater than 5

Input Sensitivity (for rated power

output) ........................ 200mV to 4.0V (1.0V at center detent)

Input Impedance ................................................... 10k ohms <

Speaker Impedance ............................... 4 or 2 ohms (Stereo),

4 ohms (Bridged)

Active Dividing Network Frequency and

Slope ....................................... 50 to 200 Hz, 12 dB per octave

Power Requirement .................. 11 – 16V DC Negative Ground

Dimensions (W x H x D)

MRV-F353, MRV-T503 ........ 240mm x 53mm x 270mm (9-

7/16" x 2-1/16" x 10-5/8")

MRV-F303 .......................... 240mm x 53mm x 400mm (9-

7/16" x 2-1/16" x 15-5/8")

MRV-T303 ........................ 240mm x 53mm x 180mm (9-

7/16" x 2-1/16" x 7-1/8")

Weight

MRV-F353, MRV-T503 ........................... 3.3 kg (7 lbs. 4 oz)

MRV-F303 .................................................. 5.0 kg (11 lbs.)

MRV-T303 ......................................... 2.2 kg (4 lbs. 13 oz)

limeted idetion tror det staves sådan
Tuner
Cd-afspiller
clarion
Pladespiller
Båndoptager
DVD/Video
Højttalere
sub
General
• Frequency Response: 26Hz - 600Hz
Dimensions
• Added Volume: 0.055 cu.ft. (Reverse Mount, Magnet Out)
• Displacement: 0.050 cu. ft. (Front Mount)
• Mounting Diameter: 231mm (9.1'')
• Mounting Depth: 172mm (6.8'')
Power Handling
• Peak Power Handling: 1500 Watts
• RMS Power Handling: 500 Watts
• Power Range: 200 - 500 Watts

mellemtone
2x 6½" 250 watt alpine r

discant
2x 1" 100 watt alpine
TV/Projektor
Ekstra udstyr
2x alpine r delefilter
